The Si-30 is suitable for all air conditioners up to 5.6 tons (20 kW / 67kBtu). Specifically designed for lifting condensate and for its usability, the Si-30 is silent regardless of the volume of condensate.
Patented Piston Technology
Quiet operation: 20 dBA
Anti siphon, prolongs the life of the pump
| Technical details | |
| Max flow rate | 5 gph 19 l/h |
| Max discharge head | 33 ft 10 m |
| Max pressure | 46 feet 14 m |
| Max suction head | 10 feet 3 m |
| Insulation class | Double insulation |
| Mains supply | 120V: (SI3000SIUS11) 230V: (SI3000SIUS23) |
| Operation conditions | 70%: 3s ON – 1s OFF |
| Protection | IP20 |
| Master pack quantity | 20 |
| Safety switch | NC 8A resistive - 250 V |
| Detection | Detection unit |
1 Si-30 pump
1 Clear PVC tube int. 1/4 (6mm) – L: 3 ¼ (1m), fitted with a « Drain Safe Device » pre-mounted.
1 Anti-vibration mounting bracket
1 5ft (1.5 m) lockable plug-in power cable: 2 power wires, 2 safety contact wires.
1 6 tie wraps, 1/10'' x 4'' (2.5 x 100 mm)
1 Detection unit - SI2958, 5 ft (1.5 m) cable
1 Detection unit installation kit:rubber elbow 90°, vent tube, mounting rail, adhesive.
| Pump Dimensions | ||
| Pump | Packaging | |
| Length | 2 5/8 inches , 66 mm | 5 5/16 inches , 135 mm |
| Width | 1 3/4 inches , 43.5 mm | 5 5/16 inches , 135 mm |
| Height | 2 3/8 inches , 60 mm | 2 3/8 inches , 90 mm |
| SOUND LEVELS | |
| at 3,3ft or 1m according to EN ISO3744 (dBA) | 20.00 |
| Safety standards | |
| UL/CSA by Intertek | |
